NASA USGS Landsat thermal sensor lights up from volcano's heat

An ash plume drifts from Paluweh volcano in Indonesia in this image, taken April 29, 2013, from the Landsat Data Continuity Mission's Operational Land Imager instrument.

Credit: Robert Simmon, NASA's Earth Observatory, using data from USGS and NASA

As the Landsat Data Continuity Mission satellite flew over Indonesia's Flores Sea April 29, it captured an image of Paluweh volcano spewing ash into the air.

The satellite's Operational Land Imager detected the white cloud of smoke and ash drifting northwest, over the green forests of the island and the blue waters of the tropical sea.

The Thermal Infrared Sensor (TIRS) on LDCM picked up even more.

By imaging the heat emanating from the 5-mile-wide volcanic island, TIRS revealed a hot spot at the top of the volcano where lava has been oozing in recent months.

The two LDCM instruments, working together, illustrate a quote from Aristotle: The whole is greater than the sum of its parts, said Betsy Forsbacka, TIRS instrument manager at NASA's Goddard Space Flight Center in Greenbelt, Md.

"Each instrument by itself is magnificent," she said. "When you put them together, with the clues that each give you on what you're seeing on Earth's surface, it's greater than either could do by themselves."

The image of Paluweh also illuminates TIRS' abilities to capture the boundaries between the hot volcanic activity and the cooler volcanic ash without the signal from the hot spot bleeding over into pixels imaging the cooler surrounding areas.

TIRS engineers tested and refined the instrument pre-launch to ensure each pixel correctly represents the heat source it images on Earth's surface.

Otherwise, Forsbacka said, it would be like shining a flashlight in your eyes—the bright light can leave you seeing spots and halos where it should be dark.

The same effect can occur with detectors. But the contrast is sharp on the Paluweh image.

A bright white hot spot, surrounded by cooler dark ash clouds, shows the volcanic activity at Paluweh volcano in the Flores Sea, Indonesia.

This thermal image was taken by the Landsat Data Continuity Mission's Thermal Infrared Sensor on April 29, 2013.

Credit: Robert Simmon, NASA's Earth Observatory, using data from USGS and NASA

"We can image the white, representing the very hot lava, and right next to it we image the gray and black from the cooler surrounding ash," Forsbacka said.

"It's exciting that we're imaging such diverse thermal activity so well. The TIRS instrument can also pick up subtle shifts of temperatures, within a 10th of a degree Celsius and, with two different thermal bands instead of the one band on previous Landsat satellites, LDCM is poised to make it easier for scientists to subtract out the effects of the atmosphere on the signal, obtaining a more accurate temperature of Earth's surface."
